Manufacturer Part Number: | BXRA-56C0700-A-04 |
---|---|
Manufacturer: | Bridgelux |
Product Category: | LED Lighting - COBs, Engines, Modules |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | LED Lighting COBs, Engines, Modules Chip On Board (COB) ES STAR White, Cool Starboard |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | BXRA-56C0700-A-04 Datasheet |
Internal Part Number | 898-BXRA-56C0700-A-04 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Lighting Product Selector | |
Category | Optoelectronics | |
Family | LED Lighting - COBs, Engines, Modules | |
Manufacturer | Bridgelux | |
Series | ES STAR | |
Packaging | - | |
Part Status | Obsolete | |
Type | Chip On Board (COB) | |
Color | White, Cool | |
CCT (K) | 5600K 4-Step MacAdam Ellipse | |
Wavelength | - | |
Configuration | Starboard | |
Flux @ Current/Temperature - Test | 780 lm (Typ) | |
Current - Test | 350mA | |
Temperature - Test | 25°C | |
Voltage - Forward (Vf) (Typ) | 18.8V | |
Lumens/Watt @ Current - Test | 118 lm/W | |
Current - Max | 500mA | |
CRI (Color Rendering Index) | 70 | |
Viewing Angle | 120° | |
Features | - | |
Size / Dimension | 19.90mm L x 19.90mm W | |
Height | 3.00mm | |
Light Emitting Surface (LES) | - | |
Lens Type | Domed | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | BXRA-56C0700-A-04 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
BXRA-56C0700-A-04 is in stock for immediate shipping now. We are the distributor of Bridgelux all series components. The condition of BXRA-56C0700-A-04 is new and unused, you can buy BXRA-56C0700-A-04 Bridgelux with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BXRA-56C0700-A-04.
