| Manufacturer Part Number: | BSB053N03LP G |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 30V 71A 2WDSON |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | BSB053N03LP G Datasheet |
| Internal Part Number | 898-BSB053N03LP G | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 12/May/2009 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | Infineon Technologies | |
| Series | OptiMOS™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 17A (Ta), 71A (Tc) | |
| Rds On (Max) @ Id, Vgs | 5.3 mOhm @ 30A, 10V | |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 29nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 2700pF @ 15V | |
| Power - Max | 42W | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 3-WDSON | |
| Supplier Device Package | MG-WDSON-2, CanPAK M™ | |
| Standard Package | 5,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | BSB053N03LP G | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
BSB053N03LP G is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of BSB053N03LP G is new and unused, you can buy BSB053N03LP G Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BSB053N03LP G.
