| Manufacturer Part Number: | BQ1001-7R |
|---|---|
| Manufacturer: | Bel Power Solutions |
| Product Category: | DC DC Converters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | DC/DC CONVERTER 3.3V 25A |
| Lead Free Status / RoHS Status: | Lead free by exemption / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | BQ1001-7R Datasheet |
| Internal Part Number | 898-BQ1001-7R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Power Solutions and Protection | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | DC DC Converters | |
| Manufacturer | Bel Power Solutions | |
| Series | Melcher Q | |
| Packaging | - | |
| Part Status | Active | |
| Type | Isolated | |
| Voltage - Input | 14.4 ~ 36 V | |
| Output | 5.1V | |
| Number of Outputs | 1 | |
| Output - 1 @ Current (Max) | 5.1 VDC @ 20A | |
| Output - 2 @ Current (Max) | - | |
| Output - 3 @ Current (Max) | - | |
| Output - 4 @ Current (Max) | - | |
| Power (Watts) | 102W | |
| Applications | ITE (Commercial), Railway | |
| Mounting Type | Chassis Mount | |
| Operating Temperature | -25°C ~ 71°C | |
| Efficiency | 86% | |
| Package / Case | - | |
| Size / Dimension | 6.46" L x 4.37" W x 0.78" H (164.0mm x 111.0mm x 19.8mm) | |
| Power (Watts) - Max | 102W | |
| Approvals | cCSAus, CE, TUV | |
| Standard Package | 10 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | BQ1001-7R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
BQ1001-7R is in stock for immediate shipping now. We are the distributor of Bel Power Solutions all series components. The condition of BQ1001-7R is new and unused, you can buy BQ1001-7R Bel Power Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BQ1001-7R.
