| Manufacturer Part Number: | BGS14AN16E6327XTSA1 |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | RF Switches |
| Available Quantity: | 12010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF Switch IC W-CDMA SP4T 3GHz 50 Ohm PG-TSNP-16-6 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | BGS14AN16E6327XTSA1 Datasheet |
| Internal Part Number | 898-BGS14AN16E6327XTSA1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| Online Catalog | BGS14AN16 | |
| Category | RF/IF and RFID | |
| Family | RF Switches | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Frequency - Lower | 100MHz | |
| Frequency - Upper | 3GHz | |
| Isolation @ Frequency | 27dB @ 2.69Hz (typ) | |
| Insertion Loss @ Frequency | 0.69dB @ 2.69GHz | |
| IIP3 | - | |
| Topology | Reflective | |
| Circuit | SP4T | |
| P1dB | - | |
| Features | - | |
| Impedance | 50 Ohm | |
| Operating Temperature | -30°C ~ 85°C | |
| Voltage - Supply | 2.85 V ~ 4.7 V | |
| RF Type | W-CDMA | |
| Package / Case | 16-WFQFN Exposed Pad | |
| Supplier Device Package | PG-TSNP-16-6 | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | BGS14AN16E6327XTSA1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
BGS14AN16E6327XTSA1 is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of BGS14AN16E6327XTSA1 is new and unused, you can buy BGS14AN16E6327XTSA1 Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BGS14AN16E6327XTSA1.
