| Manufacturer Part Number: | B82462G2821M |
|---|---|
| Manufacturer: | EPCOS (TDK) |
| Product Category: | Fixed Inductors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 820nH Shielded Wirewound Inductor 3.25A 17 mOhm Max Nonstandard |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | B82462G2821M Datasheet |
| Internal Part Number | 898-B82462G2821M | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | B82462G2 Series 16/Mar/2012 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | EPCOS (TDK) | |
| Series | B82462G2 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 820nH | |
| Tolerance | ±20% | |
| Current Rating | 3.25A | |
| Current - Saturation | 4.4A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 17 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 100kHz | |
| Ratings | AEC-Q200 | |
| Operating Temperature | -55°C ~ 150°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.248" L x 0.248" W (6.30mm x 6.30mm) | |
| Height - Seated (Max) | 0.098" (2.50mm) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | B82462G2821M | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
B82462G2821M is in stock for immediate shipping now. We are the distributor of EPCOS (TDK) all series components. The condition of B82462G2821M is new and unused, you can buy B82462G2821M EPCOS (TDK) with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for B82462G2821M.
