| Manufacturer Part Number: | B82131A5701M |
|---|---|
| Manufacturer: | EPCOS (TDK) |
| Product Category: | Fixed Inductors |
| Available Quantity: | 11010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 14µH Unshielded Wirewound Inductor 700mA 760 mOhm Axial |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | B82131A5701M Datasheet |
| Internal Part Number | 898-B82131A5701M | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | B8213x Series | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | EPCOS (TDK) | |
| Series | B82131 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Wirewound | |
| Material - Core | Iron | |
| Inductance | 14µH | |
| Tolerance | ±20% | |
| Current Rating | 700mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 760 mOhm | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 53MHz | |
| Ratings | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | - | |
| Mounting Type | Through Hole | |
| Package / Case | Axial | |
| Size / Dimension | 0.197" Dia x 0.591" L (5.00mm x 15.00mm) | |
| Height - Seated (Max) | - | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | B82131A5701M | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
B82131A5701M is in stock for immediate shipping now. We are the distributor of EPCOS (TDK) all series components. The condition of B82131A5701M is new and unused, you can buy B82131A5701M EPCOS (TDK) with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for B82131A5701M.
