| Manufacturer Part Number: | B32686S7224J564 |
|---|---|
| Manufacturer: | EPCOS (TDK) |
| Product Category: | Film Capacitors |
| Available Quantity: | 9073 Pieces |
| Unit Price: | Quote by Email |
| Description: | 0.22µF Film Capacitor 450V 1250V (1.25kV) Polypropylene (PP), Metallized Rectangular Box 1.654" L x 0.709" W (42.00mm x 18.00mm) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | B32686S7224J564 Datasheet |
| Internal Part Number | 898-B32686S7224J564 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Film Capacitors | |
| PCN Design/Specification | B32(5679)B333 Series 02/May/2014 | |
| Online Catalog | B32686S Series | |
| Category | Capacitors | |
| Family | Film Capacitors | |
| Manufacturer | EPCOS (TDK) | |
| Series | B32686S | |
| Packaging | Bulk | |
| Part Status | Active | |
| Capacitance | 0.22µF | |
| Tolerance | ±5% | |
| Voltage Rating - AC | 450V | |
| Voltage Rating - DC | 1250V (1.25kV) | |
| Dielectric Material | Polypropylene (PP), Metallized | |
| ESR (Equivalent Series Resistance) | 7 mOhm | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Chassis Mount | |
| Package / Case | Rectangular Box | |
| Size / Dimension | 1.654" L x 0.709" W (42.00mm x 18.00mm) | |
| Height - Seated (Max) | 1.280" (32.50mm) | |
| Termination | Screw Terminals | |
| Lead Spacing | 1.122" (28.50mm) | |
| Applications | Snubber | |
| Features | - | |
| Standard Package | 32 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | B32686S7224J564 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
B32686S7224J564 is in stock for immediate shipping now. We are the distributor of EPCOS (TDK) all series components. The condition of B32686S7224J564 is new and unused, you can buy B32686S7224J564 EPCOS (TDK) with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for B32686S7224J564.
