| Manufacturer Part Number: | ATSAMD20-QTRDEMO |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation Boards - Sensors |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | ATSAMD20J18 QTouch™ Touch, Capacitive Sensor Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATSAMD20-QTRDEMO Datasheet |
| Internal Part Number | 898-ATSAMD20-QTRDEMO | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Introducing Atmel Studio 7 | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | ATSAMD20 Errata Update 20/Jan/2015 | |
| Online Catalog | SMART SAM D20 QTouch® Robustness Demo Kit | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Sensors | |
| Manufacturer | Atmel | |
| Series | QTouch™ | |
| Part Status | Active | |
| Sensor Type | Touch, Capacitive | |
| Sensing Range | 4 Buttons/Keys, Slider | |
| Interface | SPI | |
| Sensitivity | - | |
| Voltage - Supply | - | |
| Embedded | Yes, MCU, 32-Bit | |
| Supplied Contents | Board | |
| Utilized IC / Part | ATSAMD20J18 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATSAMD20-QTRDEMO | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATSAMD20-QTRDEMO is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATSAMD20-QTRDEMO is new and unused, you can buy ATSAMD20-QTRDEMO Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATSAMD20-QTRDEMO.
