| Manufacturer Part Number: | ATSAMA5D35A-CN |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Embedded - Microcontrollers |
| Available Quantity: | 9134 Pieces |
| Unit Price: | Quote by Email |
| Description: | ARM® Cortex®-A5 SAMA5D3 Microcontroller IC 32-Bit 536MHz 160KB (160K x 8) ROM 324-LFBGA (15x15) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATSAMA5D35A-CN Datasheet |
| Internal Part Number | 898-ATSAMA5D35A-CN | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | SAMA5D3x MCU Schematic Appl Note | |
| Product Training Modules | SAMA5D3 Software Framework (ASF) Example of Use Studio Introduction to Software Framework (ASF) Studio Development Environment Overview Part 1 | |
| Video File | Atmel – Cross Compiling Applications for SAMA5D3 Enabling Ethernet ports on SAMA5D3 Atmel – Design with Intent Using the ARM Cortex A5 based SAMA5D3 Introducing Atmel Studio 7 Atmel START Overview | |
| Design Resources | Development Tool Selector | |
| Featured Product | Atmel - SAMA5D3 Cortex-A5 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Manufacturer | Atmel | |
| Series | SAMA5D3 | |
| Packaging | Tray | |
| Part Status | Active | |
| Core Processor | ARM® Cortex®-A5 | |
| Core Size | 32-Bit | |
| Speed | 536MHz | |
| Connectivity | CAN, EBI/EMI, Ethernet, I²C, Memory Card, SPI, SSC, UART/USART, USB | |
| Peripherals | DMA, POR, PWM, WDT | |
| Number of I/O | 160 | |
| Program Memory Size | 160KB (160K x 8) | |
| Program Memory Type | ROM | |
| EEPROM Size | - | |
| RAM Size | 128K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.65 V ~ 3.6 V | |
| Data Converters | A/D 12x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C (TA) | |
| Package / Case | 324-LFBGA | |
| Supplier Device Package | 324-LFBGA (15x15) | |
| Standard Package | 126 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATSAMA5D35A-CN | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATSAMA5D35A-CN is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATSAMA5D35A-CN is new and unused, you can buy ATSAMA5D35A-CN Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATSAMA5D35A-CN.
