Manufacturer Part Number: | ATFC-0603-8N2-BT |
---|---|
Manufacturer: | Abracon LLC |
Product Category: | Fixed Inductors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 8.2nH Unshielded Thin Film Inductor 300mA 950 mOhm Max 0603 (1608 Metric) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ATFC-0603-8N2-BT Datasheet |
Internal Part Number | 898-ATFC-0603-8N2-BT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | Abracon LLC | |
Series | ATFC-0603 | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Type | Thin Film | |
Material - Core | Ceramic | |
Inductance | 8.2nH | |
Tolerance | ±0.1nH | |
Current Rating | 300mA | |
Current - Saturation | - | |
Shielding | Unshielded | |
DC Resistance (DCR) | 950 mOhm Max | |
Q @ Freq | 15 @ 300MHz | |
Frequency - Self Resonant | 4GHz | |
Ratings | - | |
Operating Temperature | -25°C ~ 85°C | |
Frequency - Test | - | |
Mounting Type | Surface Mount | |
Package / Case | 0603 (1608 Metric) | |
Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | |
Height - Seated (Max) | 0.022" (0.55mm) | |
Standard Package | 5,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ATFC-0603-8N2-BT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ATFC-0603-8N2-BT is in stock for immediate shipping now. We are the distributor of Abracon LLC all series components. The condition of ATFC-0603-8N2-BT is new and unused, you can buy ATFC-0603-8N2-BT Abracon LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATFC-0603-8N2-BT.
