| Manufacturer Part Number: | ATAVRSB201 |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | ATmega16HVA AVR® Series Power Management, Battery Charger Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATAVRSB201 Datasheet |
| Internal Part Number | 898-ATAVRSB201 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | SB201-(1,2) Firmware User's Guide (AppNote) | |
| Product Training Modules | MCU Product Line Introduction megaAVR Introduction | |
| Video File | Introducing Atmel Studio 7 Atmel: picoPower Labs - Basic Power-Saving Techniques | |
| Design Resources | ATAVRSB201 - Schematics, BOM, & Gerbers Development Tool Selector | |
| Reference Design Library | ATAVRSB201 -2: Dual Li-Ion Smart Charger | |
| PCN Obsolescence/ EOL | WE154703 EOL 03/Dec/2015 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Atmel | |
| Series | AVR® | |
| Part Status | Obsolete | |
| Main Purpose | Power Management, Battery Charger | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | ATmega16HVA | |
| Primary Attributes | 1 ~ 4 Cells- Li-Ion, 8.4V, 880mA | |
| Secondary Attributes | - | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATAVRSB201 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATAVRSB201 is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATAVRSB201 is new and unused, you can buy ATAVRSB201 Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATAVRSB201.
