| Manufacturer Part Number: | ATAVRMC301 |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | ATtinyx61 AVR® Series Power Management, Motor Control Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATAVRMC301 Datasheet |
| Internal Part Number | 898-ATAVRMC301 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | MCU Product Line Introduction tinyAVR Introduction | |
| Video File | Introducing Atmel Studio 7 Atmel: picoPower Labs - Basic Power-Saving Techniques | |
| Design Resources | Development Tool Selector | |
| Online Catalog | ATAVRMC301 Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Atmel | |
| Series | AVR® | |
| Part Status | Active | |
| Main Purpose | Power Management, Motor Control | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | ATtinyx61 | |
| Primary Attributes | 3-Ph BLDC, Brushed DC, Stepper Motor- Controller Board | |
| Secondary Attributes | Requires ATAVRMC300 Power Driver Board | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATAVRMC301 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATAVRMC301 is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATAVRMC301 is new and unused, you can buy ATAVRMC301 Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATAVRMC301.
