| Manufacturer Part Number: | ATAVRDB101 |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | ATmega1281 AVR® Series Displays, LCD Controller Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATAVRDB101 Datasheet |
| Internal Part Number | 898-ATAVRDB101 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Introducing Atmel Studio 7 | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | AVR Development Tools 31/Aug/2012 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Atmel | |
| Series | AVR® | |
| Part Status | Obsolete | |
| Main Purpose | Displays, LCD Controller | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | ATmega1281 | |
| Primary Attributes | 128x64 Pixel, RGB Backlight, Joystick | |
| Secondary Attributes | UART (RS-232), SPI and TWI, Dataflash, Piezo Speaker | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATAVRDB101 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATAVRDB101 is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATAVRDB101 is new and unused, you can buy ATAVRDB101 Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATAVRDB101.
