| Manufacturer Part Number: | ATA6617-EK |
|---|---|
| Manufacturer: | Atmel |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9017 Pieces |
| Unit Price: | Quote by Email |
| Description: | ATA6617 - Interface, LIN + MCU Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ATA6617-EK Datasheet |
| Internal Part Number | 898-ATA6617-EK | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | MCU Product Line Introduction tinyAVR Introduction | |
| Video File | Introducing Atmel Studio 7 Atmel: picoPower Labs - Basic Power-Saving Techniques | |
| Design Resources | Development Tool Selector | |
| Online Catalog | ATA6616 and ATA6617 Development Boards | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Atmel | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Interface, LIN + MCU | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | ATA6617 | |
| Primary Attributes | LIN SiP (System-in-Package) with LIN Transceiver, AVR ATtiny167 with 16K Memory | |
| Secondary Attributes | Part also has 5V/50mA Regulator, Window Watchdog all in a QFN38 Package | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ATA6617-EK | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ATA6617-EK is in stock for immediate shipping now. We are the distributor of Atmel all series components. The condition of ATA6617-EK is new and unused, you can buy ATA6617-EK Atmel with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ATA6617-EK.
