Manufacturer Part Number: | ASMT-UWB1-NX3E2 |
---|---|
Manufacturer: | Broadcom Limited |
Product Category: | LED Indication - Discrete |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | White, Neutral 4500K LED Indication - Discrete 3.2V 4-SMD, Flat Lead Exposed Pad |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ASMT-UWB1-NX3E2 Datasheet |
Internal Part Number | 898-ASMT-UWB1-NX3E2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Other | Multiple Changes 22/Dec/2014 | |
Category | Optoelectronics | |
Family | LED Indication - Discrete | |
Manufacturer | Broadcom Limited | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Color | White, Neutral | |
Lens Color | Yellow | |
Lens Transparency | Diffused | |
Millicandela Rating | 2300mcd | |
Lens Style/Size | Round with Flat Top, 2.20mm | |
Voltage - Forward (Vf) (Typ) | 3.2V | |
Current - Test | 20mA | |
Viewing Angle | 120° | |
Mounting Type | Surface Mount | |
Wavelength - Dominant | 4500K | |
Wavelength - Peak | - | |
Features | - | |
Package / Case | 4-SMD, Flat Lead Exposed Pad | |
Supplier Device Package | 2-PLCC | |
Size / Dimension | 3.20mm L x 2.80mm W | |
Height (Max) | 1.10mm | |
Standard Package | 2,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ASMT-UWB1-NX3E2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ASMT-UWB1-NX3E2 is in stock for immediate shipping now. We are the distributor of Broadcom Limited all series components. The condition of ASMT-UWB1-NX3E2 is new and unused, you can buy ASMT-UWB1-NX3E2 Broadcom Limited with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ASMT-UWB1-NX3E2.
