| Manufacturer Part Number: | ASMC-PAB9-TV005 |
|---|---|
| Manufacturer: | Broadcom Limited |
| Product Category: | LED Indication - Discrete |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Amber 592nm LED Indication - Discrete 2.8V 4-PLCC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ASMC-PAB9-TV005 Datasheet |
| Internal Part Number | 898-ASMC-PAB9-TV005 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Optoelectronics | |
| Family | LED Indication - Discrete | |
| Manufacturer | Broadcom Limited | |
| Series | Envisium™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Color | Amber | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | 920mcd | |
| Lens Style/Size | Round with Flat Top, 2.20mm | |
| Voltage - Forward (Vf) (Typ) | 2.8V | |
| Current - Test | 50mA | |
| Viewing Angle | 120° | |
| Mounting Type | Surface Mount | |
| Wavelength - Dominant | 592nm | |
| Wavelength - Peak | 594nm | |
| Features | - | |
| Package / Case | 4-PLCC | |
| Supplier Device Package | 4-PLCC | |
| Size / Dimension | 3.20mm L x 2.80mm W | |
| Height (Max) | 2.10mm | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ASMC-PAB9-TV005 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ASMC-PAB9-TV005 is in stock for immediate shipping now. We are the distributor of Broadcom Limited all series components. The condition of ASMC-PAB9-TV005 is new and unused, you can buy ASMC-PAB9-TV005 Broadcom Limited with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ASMC-PAB9-TV005.
