| Manufacturer Part Number: | AS1336A-BQFT |
|---|---|
| Manufacturer: | ams |
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Boost Switching Regulator IC Positive Adjustable 1.8V 2 Output 500mA (Switch) 16-UFQFN Exposed Pad |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | AS1336A-BQFT Datasheet |
| Internal Part Number | 898-AS1336A-BQFT | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | AS1332x-AS13986x Devices 14/Nov/2014 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Manufacturer | ams | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Function | Step-Up | |
| Output Configuration | Positive | |
| Topology | Boost | |
| Output Type | Adjustable | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 0.8V | |
| Voltage - Input (Max) | 3.6V | |
| Voltage - Output (Min/Fixed) | 1.8V | |
| Voltage - Output (Max) | 3.6V | |
| Current - Output | 500mA (Switch) | |
| Frequency - Switching | 1.2MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-UFQFN Exposed Pad | |
| Supplier Device Package | 16-TQFN (3x3) | |
| Standard Package | 1,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | AS1336A-BQFT | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
AS1336A-BQFT is in stock for immediate shipping now. We are the distributor of ams all series components. The condition of AS1336A-BQFT is new and unused, you can buy AS1336A-BQFT ams with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AS1336A-BQFT.
