| Manufacturer Part Number: | ARV20A12Q |
|---|---|
| Manufacturer: | Panasonic Electronic Components |
| Product Category: | RF Switches |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF Switch IC General Purpose SPDT 18GHz 50 Ohm Module |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ARV20A12Q Datasheet |
| Internal Part Number | 898-ARV20A12Q | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | How to Read Date Codes | |
| Design Resources | IoT Product Selector | |
| Category | RF/IF and RFID | |
| Family | RF Switches | |
| Manufacturer | Panasonic Electric Works | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Active | |
| Frequency - Lower | DC | |
| Frequency - Upper | 18GHz | |
| Isolation @ Frequency | 60dB (min) @ 18GHz | |
| Insertion Loss @ Frequency | 0.7dB (max) @ 18GHz | |
| IIP3 | - | |
| Topology | Reflective | |
| Circuit | SPDT | |
| P1dB | - | |
| Features | - | |
| Impedance | 50 Ohm | |
| Operating Temperature | -55°C ~ 85°C | |
| Voltage - Supply | 12V | |
| RF Type | General Purpose | |
| Package / Case | Module, SMA Connectors | |
| Supplier Device Package | Module | |
| Standard Package | 5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ARV20A12Q | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ARV20A12Q is in stock for immediate shipping now. We are the distributor of Panasonic Electronic Components all series components. The condition of ARV20A12Q is new and unused, you can buy ARV20A12Q Panasonic Electronic Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ARV20A12Q.
