| Manufacturer Part Number: | APTM120U10SCAVG |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 1200V 116A SP6 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | APTM120U10SCAVG Datasheet |
| Internal Part Number | 898-APTM120U10SCAVG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | N-Channel Logic Level Gate FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | Microsemi Corporation | |
| Series | POWER MOS 7® | |
| Packaging | Bulk | |
| Part Status | Active | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 1200V (1.2kV) | |
| Current - Continuous Drain (Id) @ 25°C | 116A | |
| Rds On (Max) @ Id, Vgs | 120 mOhm @ 58A, 10V | |
| Vgs(th) (Max) @ Id | 5V @ 20mA | |
| Gate Charge (Qg) @ Vgs | 1100nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 28900pF @ 25V | |
| Power - Max | 3290W | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Chassis Mount | |
| Package / Case | SP6 | |
| Supplier Device Package | SP6 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | APTM120U10SCAVG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
APTM120U10SCAVG is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of APTM120U10SCAVG is new and unused, you can buy APTM120U10SCAVG Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for APTM120U10SCAVG.
