Manufacturer Part Number: | APT94N60L2C3G |
---|---|
Manufacturer: | Microsemi Corporation |
Product Category: | Transistors - FETs, MOSFETs - Single |
Available Quantity: | 9037 Pieces |
Unit Price: | Quote by Email |
Description: | MOSFET N-CH 600V 94A TO264 |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | APT94N60L2C3G Datasheet |
Internal Part Number | 898-APT94N60L2C3G | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | N-Channel Standard FETs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - FETs, MOSFETs - Single | |
Manufacturer | Microsemi Corporation | |
Series | - | |
Packaging | Tube | |
Part Status | Active | |
FET Type | MOSFET N-Channel, Metal Oxide | |
FET Feature | Standard | |
Drain to Source Voltage (Vdss) | 600V | |
Current - Continuous Drain (Id) @ 25°C | 94A (Tc) | |
Rds On (Max) @ Id, Vgs | 35 mOhm @ 60A, 10V | |
Vgs(th) (Max) @ Id | 3.9V @ 5.4mA | |
Gate Charge (Qg) @ Vgs | 640nC @ 10V | |
Input Capacitance (Ciss) @ Vds | 13600pF @ 25V | |
Power - Max | 833W | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Through Hole | |
Package / Case | TO-264-3, TO-264AA | |
Supplier Device Package | 264 MAX™ [L2] | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | APT94N60L2C3G | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
APT94N60L2C3G is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of APT94N60L2C3G is new and unused, you can buy APT94N60L2C3G Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for APT94N60L2C3G.
