| Manufacturer Part Number: | APT80GP60J |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Transistors - IGBTs - Modules |
| Available Quantity: | 9019 Pieces |
| Unit Price: | Quote by Email |
| Description: | IGBT Module PT Single 600V 151A 462W Chassis Mount ISOTOP® |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | APT80GP60J Datasheet |
| Internal Part Number | 898-APT80GP60J | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | APT Single Switch ISOTOP® Series | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - IGBTs - Modules | |
| Manufacturer | Microsemi Corporation | |
| Series | POWER MOS 7® | |
| Part Status | Not For New Designs | |
| IGBT Type | PT | |
| Configuration | Single | |
| Voltage - Collector Emitter Breakdown (Max) | 600V | |
| Current - Collector (Ic) (Max) | 151A | |
| Power - Max | 462W | |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 80A | |
| Current - Collector Cutoff (Max) | 1mA | |
| Input Capacitance (Cies) @ Vce | 9.84nF @ 25V | |
| Input | Standard | |
| NTC Thermistor | No | |
| Mounting Type | Chassis Mount | |
| Package / Case | ISOTOP | |
| Supplier Device Package | ISOTOP® | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | APT80GP60J | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
APT80GP60J is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of APT80GP60J is new and unused, you can buy APT80GP60J Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for APT80GP60J.
