| Manufacturer Part Number: | APGRD004 |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9012 Pieces |
| Unit Price: | Quote by Email |
| Description: | MCP2021, PIC12F615 - Lighting, RGB LED Controller Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | APGRD004 Datasheet |
| Internal Part Number | 898-APGRD004 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Microchip MCP20xx LIN Transceiver Overview | |
| Design Resources | Development Tool Selector | |
| Reference Design Library | APGRD004: LIN Interface RGB, Automotive Interior | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Online Catalog | Automotive Ambient Lighting Module Reference Design | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Lighting, RGB LED Controller | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | MCP2021, PIC12F615 | |
| Primary Attributes | 4 Tiny Boards, Each Have: RGB LED, LIN Transceiver, Voltage Regulator, MCU | |
| Secondary Attributes | LIN Commands are Interpreted to Control 16,383 Colors and 1,023 Dimming Levels | |
| Supplied Contents | 4 Boards | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | APGRD004 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
APGRD004 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of APGRD004 is new and unused, you can buy APGRD004 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for APGRD004.
