Manufacturer Part Number: | AN8016NSH-E1 |
---|---|
Manufacturer: | Panasonic Electronic Components |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Boost Regulator Positive Output Step-Up DC-DC Controller IC 10-SSOP |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AN8016NSH-E1 Datasheet |
Internal Part Number | 898-AN8016NSH-E1 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
Manufacturer | Panasonic Electronic Components | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Output Type | Transistor Driver | |
Function | Step-Up | |
Output Configuration | Positive | |
Topology | Boost | |
Number of Outputs | 1 | |
Output Phases | 1 | |
Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 14 V | |
Frequency - Switching | 2kHz ~ 1MHz | |
Duty Cycle (Max) | 80% | |
Synchronous Rectifier | No | |
Clock Sync | No | |
Serial Interfaces | - | |
Control Features | Enable, Soft Start | |
Operating Temperature | -30°C ~ 85°C (TA) | |
Package / Case | 10-FSOP (0.169", 4.30mm Width) | |
Supplier Device Package | 10-SSOP | |
Standard Package | 2,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AN8016NSH-E1 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AN8016NSH-E1 is in stock for immediate shipping now. We are the distributor of Panasonic Electronic Components all series components. The condition of AN8016NSH-E1 is new and unused, you can buy AN8016NSH-E1 Panasonic Electronic Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AN8016NSH-E1.
