Manufacturer Part Number: | AML25GBF2CA04GR |
---|---|
Manufacturer: | Honeywell Sensing and Productivity Solutions |
Product Category: | Toggle Switches |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | Toggle Switch DPDT Panel Mount, Snap-In |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AML25GBF2CA04GR Datasheet |
Internal Part Number | 898-AML25GBF2CA04GR | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | AML25 Series | |
Category | Switches | |
Family | Toggle Switches | |
Manufacturer | Honeywell Sensing and Productivity Solutions | |
Series | AML25 | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | DPDT | |
Switch Function | On-On-On | |
Current Rating | 3A (AC), 2A (DC) | |
Voltage Rating - AC | 125V | |
Voltage Rating - DC | 24V | |
Actuator Type | Paddle | |
Actuator Length | - | |
Illumination | Illuminated | |
Illumination Type, Color | LED, Red/Green | |
Illumination Voltage (Nominal) | 24 VDC | |
Mounting Type | Panel Mount, Snap-In | |
Termination Style | Solder, Quick Connect - 0.110" (2.8mm) | |
Panel Cutout Dimensions | Rectangular - 28.98mm x 19.05mm | |
Bushing Thread | - | |
Ingress Protection | - | |
Features | - | |
Actuator Material | - | |
Electrical Life | 25,000 Cycles | |
Operating Temperature | - | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AML25GBF2CA04GR | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AML25GBF2CA04GR is in stock for immediate shipping now. We are the distributor of Honeywell Sensing and Productivity Solutions all series components. The condition of AML25GBF2CA04GR is new and unused, you can buy AML25GBF2CA04GR Honeywell Sensing and Productivity Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AML25GBF2CA04GR.
