Manufacturer Part Number: | AK8963N |
---|---|
Manufacturer: | AKM Semiconductor Inc. |
Product Category: | Magnetic Sensors - Linear, Compass (ICs) |
Available Quantity: | 13010 Pieces |
Unit Price: | Quote by Email |
Description: | IC MAGNETOMETER COMPASS 16QFN |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AK8963N Datasheet |
Internal Part Number | 898-AK8963N | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | AK8963 | |
Category | Sensors, Transducers | |
Family | Magnetic Sensors - Linear, Compass (ICs) | |
Manufacturer | AKM Semiconductor Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Compass/Magnetometer | |
Technology | Hall Effect | |
Axis | X, Y, Z | |
Sensing Range | ±4.9mT | |
Voltage - Supply | 2.4 V ~ 3.6 V | |
Current - Supply (Max) | 10mA | |
Current - Output (Max) | - | |
Output Type | I²C, SPI | |
Resolution | 16 b | |
Bandwidth | - | |
Operating Temperature | -30°C ~ 85°C (TA) | |
Features | Sleep Mode | |
Package / Case | 16-WFQFN Exposed Pad | |
Supplier Device Package | 16-QFN (3x3) | |
Standard Package | 4,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AK8963N | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AK8963N is in stock for immediate shipping now. We are the distributor of AKM Semiconductor Inc. all series components. The condition of AK8963N is new and unused, you can buy AK8963N AKM Semiconductor Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AK8963N.
