ADS7-V2EBZ

ADS7-V2EBZ
Manufacturer Part Number:ADS7-V2EBZ
Manufacturer:
Product Category:Accessories
Available Quantity:9024 Pieces
Unit Price:Quote by Email
Description:ADI's High Speed ADC Evaluation Boards - Interface Board
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: ADS7-V2EBZ Datasheet
ADS7-V2EBZ´s Parameters
Internal Part Number898-ADS7-V2EBZ
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Mfg Application NotesHigh Speed ADC SPI Control Software
Understanding High Speed ADC Testing and Evaluation
Interfacing to High Speed ADCs via SPI
Design ResourcesADS7-V2EBZ Schematic
ADS7-V2EBZ BOM
ADS7-V2EBZ Cadence Brd File
Online Catalog ADS7-V2 Evaluation Board
CategoryProgrammers, Development Systems
FamilyAccessories
ManufacturerAnalog Devices Inc.
Series-
Part StatusActive
Accessory TypeInterface Board
For Use With/Related ProductsADI's High Speed ADC Evaluation Boards
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartADS7-V2EBZ
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

ADS7-V2EBZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADS7-V2EBZ is new and unused, you can buy ADS7-V2EBZ Analog Devices Inc. with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for ADS7-V2EBZ.
