| Manufacturer Part Number: | ADM00509 |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | MCP39F501 PICtail™ Series Power Management, Energy/Power Meter Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ADM00509 Datasheet |
| Internal Part Number | 898-ADM00509 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | ADM00509 Gerbers ADM00509 BOM ADM00509 Schematics Development Tool Selector | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Online Catalog | MCP39F501 Power Monitor PICtail™ Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | PICtail™ | |
| Part Status | Active | |
| Main Purpose | Power Management, Energy/Power Meter | |
| Embedded | - | |
| Utilized IC / Part | MCP39F501 | |
| Primary Attributes | - | |
| Secondary Attributes | - | |
| Supplied Contents | Board, Cables | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ADM00509 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ADM00509 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of ADM00509 is new and unused, you can buy ADM00509 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADM00509.
