Manufacturer Part Number: | ADM00460 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9016 Pieces |
Unit Price: | Quote by Email |
Description: | MCP1642B - DC/DC, Step Up 2, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ADM00460 Datasheet |
Internal Part Number | 898-ADM00460 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | MCP1642B Eval Board Layouts ADM00460 Gerbers MCP1642B Eval Board BOM MCP1642B Schematics | |
Online Catalog | MCP1642 High Current Boost Converter | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | DC/DC, Step Up | |
Outputs and Type | 2, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 3.3V, 5V | |
Current - Output | 800mA, 200mA | |
Voltage - Input | 1 V ~ 3 V | |
Regulator Topology | Boost | |
Frequency - Switching | 1MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | MCP1642B | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ADM00460 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ADM00460 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of ADM00460 is new and unused, you can buy ADM00460 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADM00460.
