Manufacturer Part Number: | ADM00458 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9045 Pieces |
Unit Price: | Quote by Email |
Description: | MCP16251, MCP1640B - DC/DC, Step Up 1, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ADM00458 Datasheet |
Internal Part Number | 898-ADM00458 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | MCP16251/1640B BOM MCP16251/1640B (ADM00458) Gerbers ADM00458 Schematic Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | MCP16251 and MCP1640B Synchronous Boost Converters Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | DC/DC, Step Up | |
Outputs and Type | 1, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 2V, 3.3V or 5V | |
Current - Output | 200mA | |
Voltage - Input | 0.35 V ~ 5.5 V | |
Regulator Topology | Boost | |
Frequency - Switching | 500kHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | MCP16251, MCP1640B | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ADM00458 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ADM00458 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of ADM00458 is new and unused, you can buy ADM00458 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADM00458.
