Manufacturer Part Number: | ADM00317 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation Boards - Digital to Analog Converters (DACs) |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MCP4706, MCP4716, MCP4726 8, 10, 12 Bit Digital to Analog Converter (DAC) Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ADM00317 Datasheet |
Internal Part Number | 898-ADM00317 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | ADM00317 Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Digital to Analog Converters (DACs) | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Number of DAC's | 3 | |
Number of Bits | 8, 10, 12 | |
Sampling Rate (Per Second) | - | |
Data Interface | - | |
Settling Time | 6µs | |
DAC Type | Voltage | |
Operating Temperature | - | |
Supplied Contents | Board | |
Utilized IC / Part | MCP4706, MCP4716, MCP4726 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ADM00317 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ADM00317 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of ADM00317 is new and unused, you can buy ADM00317 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADM00317.
