Stocking distributor of Electronic Components
Email: [email protected]
| Manufacturer Part Number: | ADM00308 |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | MTS2916A, MTS62C19A, PIC16F883 - Power Management, Motor Control, Stepper Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ADM00308 Datasheet |
| Internal Part Number | 898-ADM00308 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Reference Design Library | ADM00308: BiPolar Stepper, 10~30V, 750mA | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Online Catalog | MTS2916A Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Power Management, Motor Control, Stepper | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | MTS2916A, MTS62C19A, PIC16F883 | |
| Primary Attributes | - | |
| Secondary Attributes | - | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ADM00308 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ADM00308 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of ADM00308 is new and unused, you can buy ADM00308 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADM00308.
