| Manufacturer Part Number: | ADIS16060BCCZ |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | Motion Sensors - Gyroscopes |
| Available Quantity: | 9092 Pieces |
| Unit Price: | Quote by Email |
| Description: | Gyroscope Z (Yaw) ±80 1kHz SPI 16-LGA (8.2x8.2) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ADIS16060BCCZ Datasheet |
| Internal Part Number | 898-ADIS16060BCCZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | iSensor | |
| Video File | MEMS Based Inertial Measurement Units | |
| PCN Design/Specification | ADIS16060 Plating 18/Apr/2013 ADIS16060 Plating Revision B 09/Apr/2014 | |
| PCN Packaging | Tray Dimension 09/Feb/2016 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | ADIS16060 and ADIS16080 | |
| Category | Sensors, Transducers | |
| Family | Motion Sensors - Gyroscopes | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Packaging | Tray | |
| Part Status | Active | |
| Type | Digital | |
| Axis | Z (Yaw) | |
| Range °/s | ±80 | |
| Sensitivity (LSB/(°/s)) | 81 | |
| Sensitivity (mV/°/s) | - | |
| Bandwidth | 1kHz | |
| Output Type | SPI | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Current - Supply | 4.3mA | |
| Features | Adjustable Bandwidth, Temperature Sensor | |
| Operating Temperature | -40°C ~ 105°C (TA) | |
| Package / Case | 16-BFLGA | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ADIS16060BCCZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ADIS16060BCCZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADIS16060BCCZ is new and unused, you can buy ADIS16060BCCZ Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADIS16060BCCZ.
