Manufacturer Part Number: | ADCLK846/PCBZ |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9013 Pieces |
Unit Price: | Quote by Email |
Description: | ADCLK846 - Timing, Clock Buffer / Driver / Receiver / Translator Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ADCLK846/PCBZ Datasheet |
Internal Part Number | 898-ADCLK846/PCBZ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Mfg Application Notes | Spectrum Analyzer Solutions Magnetic Resonance Imaging (MRI) Solutions Medical Ultrasound Solutions RF Signal Source Solutions | |
Design Resources | Synchronizing Multiple AD9910 1 GSPS Direct Digital Synthesizers (CN0121) Development Tool Selector | |
Online Catalog | ADCLK846 Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Part Status | Active | |
Main Purpose | Timing, Clock Buffer / Driver / Receiver / Translator | |
Embedded | - | |
Utilized IC / Part | ADCLK846 | |
Primary Attributes | 6 LVDS/12 CMOS Outputs | |
Secondary Attributes | CMOS, LVDS Outputs | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ADCLK846/PCBZ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ADCLK846/PCBZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADCLK846/PCBZ is new and unused, you can buy ADCLK846/PCBZ Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADCLK846/PCBZ.
