| Manufacturer Part Number: | ADADC71KD |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | Data Acquisition - Analog to Digital Converters (ADC) |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | 16 Bit Analog to Digital Converter 1 Input 1 SAR 32-CDIP Bottom Brazed |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ADADC71KD Datasheet |
| Internal Part Number | 898-ADADC71KD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | 16 Bit | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| Number of Bits | 16 | |
| Sampling Rate (Per Second) | 20k | |
| Number of Inputs | 1 | |
| Input Type | Single Ended | |
| Data Interface | Parallel | |
| Configuration | ADC | |
| Ratio - S/H:ADC | - | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | Internal | |
| Voltage - Supply, Analog | ±15V | |
| Voltage - Supply, Digital | ±5V | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 32-CDIP (0.900", 22.86mm) | |
| Supplier Device Package | 32-CDIP Bottom Brazed | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ADADC71KD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ADADC71KD is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADADC71KD is new and unused, you can buy ADADC71KD Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADADC71KD.
