Manufacturer Part Number: | AD9959BCPZ-REEL7 |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | Interface - Direct Digital Synthesis (DDS) |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Direct Digital Synthesis IC 10 b 500MHz 32 b Tuning 56-LFCSP-VQ (8x8) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AD9959BCPZ-REEL7 Datasheet |
Internal Part Number | 898-AD9959BCPZ-REEL7 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Mfg Application Notes | RF Signal Source Solutions | |
Product Training Modules | Direct Digital Synthesis Tutorial Series (1 of 7): Introduction Direct Digital Synthesizer Tutorial Series (7 of 7): DDS in Action Direct Digital Synthesis Tutorial Series (3 of 7): Angle to Amplitude Converter Direct Digital Synthesis Tutorial Series (6 of 7): SINC Envelope Correction Direct Digital Synthesis Tutorial Series (4 of 7): Digital-to-Analog Converter Direct Digital Synthesis Tutorial Series (2 of 7): The Accumulator Five Things to Know About DACs Part 5: Dynamic Performance | |
Design Resources | Phase Coherent FSK Modulator (CN0186) | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | AD9958 and AD9959 | |
Category | Integrated Circuits (ICs) | |
Family | Interface - Direct Digital Synthesis (DDS) | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Resolution (Bits) | 10 b | |
Master fclk | 500MHz | |
Tuning Word Width (Bits) | 32 b | |
Voltage - Supply | 1.71 V ~ 1.96 V | |
Operating Temperature | -40°C ~ 85°C | |
Mounting Type | Surface Mount | |
Package / Case | 56-VFQFN Exposed Pad, CSP | |
Supplier Device Package | 56-LFCSP-VQ (8x8) | |
Standard Package | 750 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AD9959BCPZ-REEL7 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AD9959BCPZ-REEL7 is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of AD9959BCPZ-REEL7 is new and unused, you can buy AD9959BCPZ-REEL7 Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AD9959BCPZ-REEL7.
