| Manufacturer Part Number: | AD9956YCPZ-REEL7 |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | Interface - Direct Digital Synthesis (DDS) |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Direct Digital Synthesis IC 14 b 3GHz 48 b Tuning 48-LFCSP-VQ (7x7) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | AD9956YCPZ-REEL7 Datasheet |
| Internal Part Number | 898-AD9956YCPZ-REEL7 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Solution for Wireless Communication Tester | |
| Product Training Modules | Direct Digital Synthesis Tutorial Series (1 of 7): Introduction Direct Digital Synthesizer Tutorial Series (7 of 7): DDS in Action Direct Digital Synthesis Tutorial Series (3 of 7): Angle to Amplitude Converter Direct Digital Synthesis Tutorial Series (6 of 7): SINC Envelope Correction Direct Digital Synthesis Tutorial Series (4 of 7): Digital-to-Analog Converter Direct Digital Synthesis Tutorial Series (2 of 7): The Accumulator Five Things to Know About DACs Part 5: Dynamic Performance | |
| PCN Packaging | Sawn Packaging 22/Apr/2016 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Direct Digital Synthesis (DDS) | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Resolution (Bits) | 14 b | |
| Master fclk | 3GHz | |
| Tuning Word Width (Bits) | 48 b | |
| Voltage - Supply | 1.71 V ~ 1.96 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 48-VFQFN Exposed Pad, CSP | |
| Supplier Device Package | 48-LFCSP-VQ (7x7) | |
| Standard Package | 750 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | AD9956YCPZ-REEL7 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
AD9956YCPZ-REEL7 is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of AD9956YCPZ-REEL7 is new and unused, you can buy AD9956YCPZ-REEL7 Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AD9956YCPZ-REEL7.
