Manufacturer Part Number: | AD9520-1/PCBZ |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9014 Pieces |
Unit Price: | Quote by Email |
Description: | AD9520-1 - Timing, Clock Generator Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AD9520-1/PCBZ Datasheet |
Internal Part Number | 898-AD9520-1/PCBZ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Synchronizing Multiple AD9910 1 GSPS Direct Digital Synthesizers (CN0121) Phase Coherent FSK Modulator (CN0186) AD9520 Eval Brd Schematic AD9520 BOM Development Tool Selector | |
Online Catalog | AD9520-x Evaluation Boards | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Part Status | Active | |
Main Purpose | Timing, Clock Generator | |
Embedded | No | |
Utilized IC / Part | AD9520-1 | |
Primary Attributes | 12 LVPECL/24 CMOS Output Clock Generator with 2.5GHz VCO | |
Secondary Attributes | SPI and I2C Compatible Control Port | |
Supplied Contents | Board, Cable, Power Supply | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AD9520-1/PCBZ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AD9520-1/PCBZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of AD9520-1/PCBZ is new and unused, you can buy AD9520-1/PCBZ Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AD9520-1/PCBZ.
