| Manufacturer Part Number: | AD-FMCMOTCON2-EBZ |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | - Power Management, Motor Control Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | AD-FMCMOTCON2-EBZ Datasheet |
| Internal Part Number | 898-AD-FMCMOTCON2-EBZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | DigiKey’s 2015 Holiday Gift Guide – Another Geek Moment Non-ideal Effects in a Motor Drive Analog Devices' Isolation Technology for Industrial Motor Control | |
| Design Resources | Development Tool Selector | |
| Online Catalog | FMCMOTCON2 Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Power Management, Motor Control | |
| Embedded | - | |
| Utilized IC / Part | - | |
| Primary Attributes | Brushless DC (BLDC) or Permanent Magnet Synchronous Motors (PMSM) | |
| Secondary Attributes | Reverse Protection | |
| Supplied Contents | 2 Boards | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | AD-FMCMOTCON2-EBZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
AD-FMCMOTCON2-EBZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of AD-FMCMOTCON2-EBZ is new and unused, you can buy AD-FMCMOTCON2-EBZ Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AD-FMCMOTCON2-EBZ.
