| Manufacturer Part Number: | ACPL-W70L-020E |
|---|---|
| Manufacturer: | Broadcom Limited |
| Product Category: | Optoisolators - Logic Output |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Logic Output Optoisolator 15MBd Push-Pull, Totem Pole 5000Vrms 1 Channel 10kV/µs CMTI 6-SSO |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ACPL-W70L-020E Datasheet |
| Internal Part Number | 898-ACPL-W70L-020E | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Isolators | |
| Family | Optoisolators - Logic Output | |
| Manufacturer | Broadcom Limited | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Number of Channels | 1 | |
| Inputs - Side 1/Side 2 | 1/0 | |
| Voltage - Isolation | 5000Vrms | |
| Common Mode Transient Immunity (Min) | 10kV/µs | |
| Input Type | DC | |
| Output Type | Push-Pull, Totem Pole | |
| Current - Output / Channel | 10mA | |
| Data Rate | 15MBd | |
| Propagation Delay tpLH / tpHL (Max) | 55ns, 55ns | |
| Rise / Fall Time (Typ) | 3.5ns, 3.5ns | |
| Voltage - Forward (Vf) (Typ) | 1.5V | |
| Current - DC Forward (If) (Max) | 10mA | |
| Voltage - Supply | 3 V ~ 3.6 V, 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SOIC (0.268", 6.80mm Width) | |
| Supplier Device Package | 6-SSO | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ACPL-W70L-020E | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
