| Manufacturer Part Number: | ACO-25.000MHZ-ECS |
|---|---|
| Manufacturer: | Abracon LLC |
| Product Category: | Oscillators |
| Available Quantity: | 10009 Pieces |
| Unit Price: | Quote by Email |
| Description: | 25MHz HCMOS, TTL XO (Standard) Oscillator Through Hole 5V 45mA |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ACO-25.000MHZ-ECS Datasheet |
| Internal Part Number | 898-ACO-25.000MHZ-ECS | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | ACO.pdf ACO.stp | |
| Online Catalog | ACO Series | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Manufacturer | Abracon LLC | |
| Series | ACO | |
| Packaging | Tray | |
| Part Status | Active | |
| Type | XO (Standard) | |
| Frequency | 25MHz | |
| Function | - | |
| Output | HCMOS, TTL | |
| Voltage - Supply | 5V | |
| Frequency Stability | ±50ppm | |
| Operating Temperature | -20°C ~ 70°C | |
| Current - Supply (Max) | 45mA | |
| Ratings | - | |
| Mounting Type | Through Hole | |
| Size / Dimension | 0.795" L x 0.496" W (20.20mm x 12.60mm) | |
| Height | 0.200" (5.08mm) | |
| Package / Case | 14-DIP, 4 Leads (Full Size, Metal Can) | |
| Current - Supply (Disable) (Max) | - | |
| Standard Package | 25 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ACO-25.000MHZ-ECS | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ACO-25.000MHZ-ECS is in stock for immediate shipping now. We are the distributor of Abracon LLC all series components. The condition of ACO-25.000MHZ-ECS is new and unused, you can buy ACO-25.000MHZ-ECS Abracon LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ACO-25.000MHZ-ECS.
