Manufacturer Part Number: | AC164130-2 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9022 Pieces |
Unit Price: | Quote by Email |
Description: | MCP2021, MCP2551 PICtail™ Plus Series Interface, CAN, ECAN LIN Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AC164130-2 Datasheet |
Internal Part Number | 898-AC164130-2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | 8-bit PIC® Microcontroller Portfolio Microchip MCP20xx LIN Transceiver Overview | |
Design Resources | Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | AC164130-2 Daughter Board | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Microchip Technology | |
Series | PICtail™ Plus | |
Part Status | Active | |
Main Purpose | Interface, CAN, ECAN LIN | |
Embedded | No | |
Utilized IC / Part | MCP2021, MCP2551 | |
Primary Attributes | 2 CAN and 2 LIN Transceivers, 4 Socketed IC's | |
Secondary Attributes | Requires Explorer 16 Board | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AC164130-2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AC164130-2 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of AC164130-2 is new and unused, you can buy AC164130-2 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AC164130-2.
