Manufacturer Part Number: | AC164125 |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9014 Pieces |
Unit Price: | Quote by Email |
Description: | PICtail™ interface, PICtail Plus™ PICtail™ Series Audio, Voice Record/Playback Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | AC164125 Datasheet |
Internal Part Number | 898-AC164125 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Mfg Application Notes | Adaptive Differential Pulse Code Modulation | |
Design Resources | Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | Speech Playback PICtail™ Plus Daughter Board | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Microchip Technology | |
Series | PICtail™ | |
Part Status | Active | |
Main Purpose | Audio, Voice Record/Playback | |
Embedded | Yes, MCU, 8-Bit | |
Utilized IC / Part | PICtail™ interface, PICtail Plus™ | |
Primary Attributes | On-board 250 Kbit SPI Serial EEPROM for voice storage | |
Secondary Attributes | Mono Output via On-Board Speaker or Stereo Output via Headphones | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | AC164125 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
AC164125 is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of AC164125 is new and unused, you can buy AC164125 Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AC164125.
