| Manufacturer Part Number: | AC1020 |
|---|---|
| Manufacturer: | Talema Group LLC |
| Product Category: | Current Sense Transformers |
| Available Quantity: | 13619 Pieces |
| Unit Price: | Quote by Email |
| Description: | TRANSFORMER CURRENT 20.0 AMP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | AC1020 Datasheet |
| Internal Part Number | 898-AC1020 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Understanding and Using Current Transformers | |
| Online Catalog | AC | |
| Category | Transformers | |
| Family | Current Sense Transformers | |
| Manufacturer | Talema Group LLC | |
| Series | AC | |
| Part Status | Active | |
| Turns Ratio - Primary:Secondary | 1000 : 1 | |
| Frequency | 50Hz ~ 60Hz | |
| Inductance | - | |
| Current Rating | 20A | |
| DC Resistance (DCR) | 41.8 Ohm | |
| E.T. | - | |
| Mounting Type | Through Hole | |
| Size / Dimension | 23.80mm L x 11.12mm W | |
| Height - Seated (Max) | 23.80mm | |
| Termination Style | PC Pin | |
| Standard Package | 250 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | AC1020 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
AC1020 is in stock for immediate shipping now. We are the distributor of Talema Group LLC all series components. The condition of AC1020 is new and unused, you can buy AC1020 Talema Group LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AC1020.
