9402-05-20

9402-05-20
Manufacturer Part Number:9402-05-20
Manufacturer:
Product Category:Signal Relays, Up to 2 Amps
Available Quantity:9356 Pieces
Unit Price:Quote by Email
Description:RF Relay SPST-NO (1 Form A) Surface Mount
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):2 (1 Year)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 9402-05-20 Datasheet
9402-05-20´s Parameters
Internal Part Number898-9402-05-20
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Mfg Application NotesReed Relays Technical, Appl Into
Online Catalog 9400 Series
CategoryRelays
FamilySignal Relays, Up to 2 Amps
ManufacturerCoto Technology
Series9400
PackagingTube
Part StatusActive
Relay TypeRF
Coil TypeNon Latching
Coil Current25mA
Coil Voltage5VDC
Contact FormSPST-NO (1 Form A)
Contact Rating (Current)500mA
Switching Voltage200VAC, 200VDC - Max
Turn On Voltage (Max)3.75 VDC
Turn Off Voltage (Min)0.4 VDC
Operate Time0.4ms
Release Time0.2ms
Features-
Mounting TypeSurface Mount
Termination StyleJ Lead
Contact Material-
Coil Power-
Coil Resistance200 Ohms
Operating Temperature-20°C ~ 85°C
Standard Package 25
Weight0.001 KG
ApplicationEmail for details
Replacement Part9402-05-20
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

9402-05-20 is in stock for immediate shipping now. We are the distributor of Coto Technology all series components. The condition of 9402-05-20 is new and unused, you can buy 9402-05-20 Coto Technology with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 9402-05-20.
