| Manufacturer Part Number: | 91596-118LF |
|---|---|
| Manufacturer: | Amphenol FCI |
| Product Category: | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 18 Position Receptacle, Bottom Entry Connector 0.079" (2.00mm) Surface Mount Gold |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 91596-118LF Datasheet |
| Internal Part Number | 898-91596-118LF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Mezzselect Tool - Another Geek Moment | |
| Featured Product | MezzSelect | |
| PCN Design/Specification | Raw Plastic PCT to PA4T 10/May/2013 | |
| PCN Assembly/Origin | LPVCC Devices 07/Jan/2010 Minitek 2.00mm 29/Oct/2011 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
| Manufacturer | Amphenol FCI | |
| Series | Minitek® MezzSelect™, Basics+ | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Connector Type | Receptacle, Bottom Entry | |
| Contact Type | Female Socket | |
| Number of Positions | 18 | |
| Number of Positions Loaded | All | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.079" (2.00mm) | |
| Mounting Type | Surface Mount | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Black | |
| Standard Package | 990 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 91596-118LF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
91596-118LF is in stock for immediate shipping now. We are the distributor of Amphenol FCI all series components. The condition of 91596-118LF is new and unused, you can buy 91596-118LF Amphenol FCI with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 91596-118LF.
