Manufacturer Part Number: | 88AB2-143 |
---|---|
Manufacturer: | Grayhill Inc. |
Product Category: | Keypad Switches |
Available Quantity: | 9348 Pieces |
Unit Price: | Quote by Email |
Description: | Keypad Switch 12 Polyester Overlay Keys Snap Dome Contacts Matrix Output Non-Illuminated 0.01A @ 24VDC |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 88AB2-143 Datasheet |
Internal Part Number | 898-88AB2-143 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Keypads | |
RoHS Information | Compliance Status by Product Type | |
Online Catalog | 88 Series | |
Category | Switches | |
Family | Keypad Switches | |
Manufacturer | Grayhill Inc. | |
Series | 88 | |
Part Status | Active | |
Switch Type | Snap Dome | |
Number of Keys | 12 | |
Matrix (Columns x Rows) | 3 x 4 | |
Illumination | Non-Illuminated | |
Legend Type | Fixed | |
Key Type | Polyester Overlay | |
Output Type | Matrix | |
Legend | Telephone Format | |
Legend Color | Black | |
Key Color | White | |
Mounting Type | Panel Mount, Front or Rear | |
Termination Style | Pin Header | |
Panel Cutout Dimensions | - | |
Operating Temperature | -40°C ~ 80°C | |
Ingress Protection | IP42 | |
Illumination Voltage (Nominal) | - | |
Contact Rating @ Voltage | 0.01A @ 24VDC | |
Features | - | |
Operational Life | 3,000,000 Cycles | |
Approvals | - | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 88AB2-143 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
88AB2-143 is in stock for immediate shipping now. We are the distributor of Grayhill Inc. all series components. The condition of 88AB2-143 is new and unused, you can buy 88AB2-143 Grayhill Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 88AB2-143.
