| Manufacturer Part Number: | 8134-HC-8P2 |
|---|---|
| Manufacturer: | TE Connectivity Potter & Brumfield Relays |
| Product Category: | Terminals - PC Pin Receptacles, Socket Connectors |
| Available Quantity: | 58986 Pieces |
| Unit Price: | Quote by Email |
| Description: | Pin Receptacle Connector 0.025" ~ 0.035" (0.64mm ~ 0.89mm) No Tail Press-Fit |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 8134-HC-8P2 Datasheet |
| Internal Part Number | 898-8134-HC-8P2 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | 7-1437514-0 Statement of Compliance RoHS 2 Statement | |
| 3D Model | 7-1437514-0.pdf | |
| PCN Design/Specification | 147699 Drawing 20/Oct/2014 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - PC Pin Receptacles, Socket Connectors | |
| Manufacturer | TE Connectivity AMP Connectors | |
| Series | HOLTITE | |
| Packaging | Bulk | |
| Part Status | Active | |
| Tail Type | No Tail | |
| Termination | Press-Fit | |
| Length - Overall | 0.136" (3.45mm) | |
| Accepts Pin Diameter | 0.025" ~ 0.035" (0.64mm ~ 0.89mm) | |
| Mounting Hole Diameter | 0.058" (1.47mm) | |
| Pin Hole Diameter | 0.042" (1.07mm) | |
| Flange Diameter | - | |
| Tail Diameter | - | |
| Socket Depth | - | |
| Contact Material | Beryllium Copper | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 25µin (0.63µm) | |
| Features | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Board Thickness | 0.030" (0.76mm) | |
| Insertion Force | - | |
| Standard Package | 50,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 8134-HC-8P2 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
8134-HC-8P2 is in stock for immediate shipping now. We are the distributor of TE Connectivity Potter & Brumfield Relays all series components. The condition of 8134-HC-8P2 is new and unused, you can buy 8134-HC-8P2 TE Connectivity Potter & Brumfield Relays with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 8134-HC-8P2.
