| Manufacturer Part Number: | 809-43-040-10-001000 |
|---|---|
| Manufacturer: | Mill-Max Manufacturing Corp. |
| Product Category: | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets |
| Available Quantity: | 9037 Pieces |
| Unit Price: | Quote by Email |
| Description: | 40 (30 + 10 Power) Position Receptacle Connector Gold Through Hole |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 809-43-040-10-001000 Datasheet |
| Internal Part Number | 898-809-43-040-10-001000 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Combination Connectors for Signal and Power | |
| Online Catalog | 809 Series | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Headers, Receptacles, Female Sockets | |
| Manufacturer | Mill-Max Manufacturing Corp. | |
| Series | 809 | |
| Packaging | Tube | |
| Part Status | Active | |
| Connector Type | Receptacle | |
| Number of Positions | 40 (30 + 10 Power) | |
| Number of Positions Loaded | All | |
| Pitch | - | |
| Number of Rows | - | |
| Row Spacing | - | |
| Height Stacking (Mating) | 0.415" (10.54mm) | |
| Height Above Board | 0.375" (9.52mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Features | - | |
| Color | Black | |
| Standard Package | 10 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 809-43-040-10-001000 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
809-43-040-10-001000 is in stock for immediate shipping now. We are the distributor of Mill-Max Manufacturing Corp. all series components. The condition of 809-43-040-10-001000 is new and unused, you can buy 809-43-040-10-001000 Mill-Max Manufacturing Corp. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 809-43-040-10-001000.
