7822

7822
Manufacturer Part Number:7822
Manufacturer:
Product Category:Terminals - Quick Connects, Quick Disconnect Connectors
Available Quantity:9767 Pieces
Unit Price:Quote by Email
Description:0.250" (6.35mm) Quick Connect Male Solder Connector Non-Mating End Insulated
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 7822 Datasheet
7822´s Parameters
Internal Part Number898-7822
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS InformationRoHS Compliance Statement
Featured ProductQuick-Fit Terminals
Online Catalog Quick Connects - Keystone Electronics
CategoryConnectors, Interconnects
FamilyTerminals - Quick Connects, Quick Disconnect Connectors
ManufacturerKeystone Electronics
Series-
PackagingBulk
Part StatusActive
Terminal TypeHeader
GenderMale
Tab Width0.250" (6.35mm)
Tab Thickness0.032" (0.81mm)
Tab Length0.307" (7.80mm)
Length - Overall-
TerminationSolder
Wire Gauge-
InsulationNon-Mating End Insulated
Mounting TypeThrough Hole, Right Angle
Features2 Tabs
ColorBlack
Contact MaterialSteel
Contact FinishTin
Insulation Diameter-
Standard Package 100
Weight0.001 KG
ApplicationEmail for details
Replacement Part7822
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

7822 is in stock for immediate shipping now. We are the distributor of Keystone Electronics all series components. The condition of 7822 is new and unused, you can buy 7822 Keystone Electronics with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 7822.
