Manufacturer Part Number: | 74AUP1G00FS3-7 |
---|---|
Manufacturer: | Diodes Incorporated |
Product Category: | Logic - Gates and Inverters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | NAND Gate IC 1 Channel 4-X2DFN (0.80x0.80) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 74AUP1G00FS3-7 Datasheet |
Internal Part Number | 898-74AUP1G00FS3-7 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | 74AUP | |
Category | Integrated Circuits (ICs) | |
Family | Logic - Gates and Inverters | |
Manufacturer | Diodes Incorporated | |
Series | 74AUP | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Logic Type | NAND Gate | |
Number of Circuits | 1 | |
Number of Inputs | 2 | |
Features | - | |
Voltage - Supply | 0.8 V ~ 3.6 V | |
Current - Quiescent (Max) | 0.5µA | |
Current - Output High, Low | 4mA, 4mA | |
Logic Level - Low | 0.7 V ~ 0.9 V | |
Logic Level - High | 1.6 V ~ 2 V | |
Max Propagation Delay @ V, Max CL | 6.5ns @ 3.3V, 30pF | |
Operating Temperature | -40°C ~ 125°C | |
Mounting Type | Surface Mount | |
Supplier Device Package | 4-X2DFN (0.80x0.80) | |
Package / Case | 4-XFDFN Exposed Pad | |
Standard Package | 5,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 74AUP1G00FS3-7 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
74AUP1G00FS3-7 is in stock for immediate shipping now. We are the distributor of Diodes Incorporated all series components. The condition of 74AUP1G00FS3-7 is new and unused, you can buy 74AUP1G00FS3-7 Diodes Incorporated with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 74AUP1G00FS3-7.
